SPECIFICATIONS 13
2
ENOM00013-0
Remark: Specifications are subject to change without notice.
*1 With propeller
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
MF, EF, ET (EFT)
Item Model
MFS 25/30D
MF EF ET (EFT)
with basic tiller handle
Overall Length mm (in) 1113 (43.80)
Overall Width mm (in) 401 (15.80)
Overall Height mm (in) S : 1216 (47.85) L : 1343 (52.85)
Transom Height mm (in) S : 425 (16.75) L : 552 (21.75)
Weight*1
S kg (lb) 58.0 (128) 62.0 (137) 69.0 (152)
L kg (lb) 58.5 (129) 62.5 (138) 69.5 (153)
Engine Type 4 stroke
Number of Cylinder 3
Piston Displacement cm
3
(cu.in.) 500 (30.50)
Bore x Stroke mm (in) 61 x 57 (2.40) x (2.25)
Max. Output kW (PS) 18.4 (25) 22.1 (30)
Max. Operating Range min
-1
(rpm) 25D : 5000 - 6000, 30D : 5500 - 6500
Idle Speed min
-1
(rpm) 850
Exhaust System Through-hub exhaust
Lubrication System Wet sump
Cooling System Water cooling
Starting System Electric and Recoil
Ignition System Flywheel Magneto CD ignition
Alternator 12V - 17.5A
Steering Angle Degree 76
Trim Position 64
Trim Up Angle Degree 72 74
Gear Shift Dog clutch (F-N-R)
Gear Reduction Ratio 26 : 12 (2.17)
Operator Sound Pressure
(ICOMIA 39/94 Rev.1) dB (A)
83.2
Hand Vibration Level
(ICOMIA 38/94 Rev.1) m/s
2
4
