TOHATSU MFS 25d User Manual

SPECIFICATIONS 15
2
ENOM00013-0
Remark: Specifications are subject to change without notice.
*1 With propeller
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
ET (EHT), ET (EPT)
Item Model
MFS 25/30D
ET (EHT) ET (EPT)
with multifunction tiller handle
with RC
Overall Length mm (in) 1360 (53.55) 732 (28.80)
Overall Width mm (in) 389 (15.30)
Overall Height mm (in) S : 1216 (47.85) L : 1343 (52.85)
Transom Height mm (in) S : 425 (16.75) L : 552 (21.75)
Weight*1
S kg (lb) 71.0 (156) 67.0 (148)
L kg (lb) 71.5 (157) 67.5 (149)
Engine Type 4 stroke
Number of Cylinder 3
Piston Displacement cm
3
(cu.in.) 500 (30.50)
Bore x Stroke mm (in) 61 x 57 (2.40) x (2.25)
Max. Output kW (PS) 18.4 (25) 22.1 (30)
Max. Operating Range min
-1
(rpm) 25D : 5000 - 6000, 30D : 5500 - 6500
Idle Speed min
-1
(rpm) 850
Exhaust System Through-hub exhaust
Lubrication System Wet sump
Cooling System Water cooling
Starting System Electric and Recoil
Ignition System Flywheel Magneto CD ignition
Alternator 12V - 17.5A
Steering Angle Degree 76
Trim Position 4
Trim Up Angle Degree 74
Gear Shift Dog clutch (F-N-R)
Gear Reduction Ratio 26 : 12 (2.17)
Operator Sound Pressure
(ICOMIA 39/94 Rev.1) dB (A)
83.2
Hand Vibration Level
(ICOMIA 38/94 Rev.1) m/s
2
4-
