ENGINE OPERATION 39
7
a sealing mechanism as shown below: other-
wise fuel spillage may occur when the con-
nector is connected to the engine.
Do not connect fuel connector except when
operating engine. Fuel leakage is a fire or
explosion hazard, which can cause serious
injury or death.
ENOW00947-0
When using a separate tank, be sure that the
fuel line is not kinked and is connected
securely.
1. Fully open the air vent screw on the
fuel tank cap.
1. Air vent screw
2. Fuel tank cap
2. Open the fuel tank cap slowly and
release internal pressure completely.
After that, close the fuel tank cap.
Connector type
3-1.Connect the fuel connector to the
engine and fuel tank.
1. Fuel connector
2. Push
3. Insert
1. Pull
2. Insert
Hose joint type
3-1.Remove the cap from the fuel joint.
Connect the fuel hose of the primer
bulb and secure with a hose band.
3-2.Connect the primer bulb to the fuel
tank.
1. Joint
2. Cap
CAUTION
