TOHATSU MFS 4D User Manual

SPECIFICATIONS 13
2
ENOM00401-0
Remark: Specifications subject to change without notice.
*1: With propeller, with battery cable.
*2: Equippted only for SP model, the other models OPTION.
*3: Transom angle is at -12°
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
MF
Model
MFS4/5/6DD
MFS5/
6DS
MFS6DS
SP
Item Dual Tank Separate Tank
Overall Length mm (in) 823 (32.4)
Overall Width mm (in) 345 (13.6)
Overall Height mm (in)
S : 1051 (41.4)
L : 1178 (46.4)
UL : 1305 (51.4)
S : 1030 (40.6)
L : 1157 (45.6)
UL : 1284 (50.6)
Transom Height mm (in) S : 436 (17.2) L : 563 (22.2) UL : 690 (27.2)
Weight*1
S kg (lb) 26.0 (57) 25.5 (56)
L kg (lb) 26.5 (59) 26.0 (57)
UL kg (lb) 27.0 (60) 26.5 (59)
Engine Type 4 stroke
Number of Cylinder 1
Piston Displacement cm
3
(cu.in.) 123 (7.5)
Bore x Stroke mm (in) 59 x 45 (2.30 x 1.75)
Max. Output kW (PS) 2.9 (4) 3.7 (5) 4.4 (6)
Max. Operating Range min
-1
(rpm) 4D & 5D : 4500 - 5500 6D : 5000 - 6000
Idle Speed in Forward Gear min
-1
(rpm) 1150
Idle Speed in Neutral Gear min
-1
(rpm) 1300
Exhaust System Through-hub exhaust
Lubrication System Wet sump (Trochoid pump)
Cooling System Water cooling (with thermostat)
Starting System Manual starter
Ignition System Flywheel Magneto CD ignition
Alternator 12V - 5A*2
Steering Angle Degree 150
Trim Angle*3 Degree -8 - 12
Trim Position 6
Tilt Up Angle*3 Degree 63
Gear Shift Dog clutch (F-N-R)
Gear Reduction Ratio 2.15 (28:13)
Emisson Controul System EM (Engine modification)
Operator Sound Pressure
(ICOMIA 39/94 Rev.1) dB (A)
79.0
Hand Vibration Level
(ICOMIA 38/94 Rev.1) m/s
2
6.8
