PARTS NAME16
3
3
1
2
4
5
6
7
8
9
13
12
11
10
ENOF01404-2
ENOM00822-0
Remote control box & Fuel tank
1
Control Lever
2
Neutral lock arm
3
PTT switch
4
Free throttle lever
5
Main switch
6
Stop switch
7
Stop switch lock
8
Stop switch lanyard
9
Air vent screw
10
Fuel tank cap
11
Fuel connector (Engine side)
12
Primer bulb
13
Fuel connector (Fuel tank
side)
