②
Recommended oil
Use an automatic transmission
fluid or equivalent.
Recommended oils are as shown
below.
ATF Dexron III
③
Air purging from the Power Trim
and Tilt unit.
Entrapped air in the Power Trim
& Tilt unit will cause poor tilting
movement and increased noise.
With the outboard motor mounted
on the boat, set the manual release
valve to the Manual side, and
tilt the outboard motor manually
up/down 5-6 times while checking
the oil level. When done, close
the valve by turning it clockwise
towards the Power side.
49
1
2
3
4
5
6
7
8
9
10
11
12
13
INSPECTION AND MAINTENANCE
Do not unscrew the oil plug with the
outboard motor tilted down. Pressurized
oil in the oil tank may spurt out.
