User Manual
Electrical connections
32
7
7.2 Power connection
Fig. 9: AUTOSORT power connection - standard TN-S Power Net
Fig. 10: AUTOSORT power connection - 480V transformer
The AUTOSORT system has to be supplied continuously with an undisturbed electrical sine
voltage. During normal operation, the system must not be switched off/on and has to be
powered uninterruptedly! The fluctuations in the main supply voltage must not exceed +/-10%
of the nominal supply voltage!
= 230V AC
==
3
U
2
U
1
U
= 400V AC
==
23
U
13
U
12
U
3
U
2
U
1
U
13
U
23
U
12
U
400 V AC
3 -phase rotary net
mains transformer
230 V AC
50 / 60 Hz
16 A (20A)
Power Connection Example
Overload
Protection
(Lightning)
L1
PE
N
L3
L2
LNPE
AUTOSORT Control Cabinets
L3
L2
L1
Control Unit AUTOSORT: 230 VAC 16A
Optional: Valve Block Heating Cabinet
Optional: Network Cabinet
TOMRA Sorting Scope of supply
5 Wire 3 Wire
Customer Power Network
TN-S
Connection cables, 3 wire (customer)
AUTOSORT
230 V AC
50 / 60 Hz
10 A
LNPE
3 Wire
VB Heating
(Option)
230 V AC
50 / 60 Hz
16 A (20A)
LNPE
3 Wire
Network Cabinet
(Option)
480 V AC
3 -phase rotary net
mains transformer
230 V AC
50 / 60 Hz
16 A (20A)
Power Connection Example
Overload
Protection
(Lightning)
L1
PE
N
L3
L2
LNPE
AUTOSORT Control Cabinets
L3
L2
L1
230 V
480 V
528
480
432
Control Unit AUTOSORT: 230 VAC 16A
Optional: Valve Block Heating Cabinet
Optional: Network Cabinet
Optional: Transformer 480V 1 phase
TOMRA Sorting scope of supply
5 Wire 3 Wire
Customer Power Network
Transformer Cabinet
La
TN-S
Lb PE
Connection cable, 3 wire
Customer or
Optional TOMRA Sorting scope of supply
Customer
Connection cables, 3 wire (customer)
AUTOSORT
230 V AC
50 / 60 Hz
10 A
LNPE
230 V
480 V
528
480
432
3 Wire
La Lb PE
VB Heating
(Option)
230 V AC
50 / 60 Hz
16 A (20A)
LNPE
230 V
480 V
528
480
432
3 Wire
La Lb PE
Network Cabinet
(Option)
Alternative Connections: La - L1, Lb - L3 / La - L2, Lb -L3
= 277V AC
==
3
U
2
U
1
U
= 480V AC
==
23
U
13
U
12
U
3
U
2
U
1
U
13
U
23
U
12
U
