Anslutningsöversikt
218
SV
Ans-
lutning-
söversikt
* Se Tekniska data på sidan235
** Se till att den här säkringen är avsäkrad
med 15 A.
SMB
GPS antenn
S
MB
GP
S
antenn
TomTom GO 7000
TomTom PRO 7xxx
TomTom LINK 300/310
Bluetooth
TM
Strömkabel
+9-30VKlämma 30**
JORDKlämma 31
IN 1+9-30V (grön/blå)
(brun)
(röd)
F1 2Af*
F2 2Af*
F3 2Af*
(svart)
IGN
(+9-30V)Klämma 15**
Tillbehör
