After connecting the ST8 to the computer via the
USB cable in the box. the computer will recognize the
USB flash drive named Toolkit. Download the upgrade
file app.upg on the official website to overwrite the
files in the USB flash drive to upgrade the firmware.
Specification
Input voltage
7-28V@MAX 10A
Main output port
5.0V-28.0V@MAX 10A
Signal port
Output voltage
5.0V-8.4V@MAX 4A/S1-S4
5.0V-8.4V@MAX 4A/S4 Ext.
Output signal
100us-2900us@33-1000Hz @S1-S4
PWM 500us-2500us@S5
PPM 8CH@S5 SBUS 16CH@S5
P1 rotation range
1000us-2000us@P1
MicroUSB
Upgrade@USB3.0
LCD display
2.4 inch TFT RGB 320*240 resolution
Product
Size
99mm*68mm*26mm
Weight
120g
packing
Size
105mm*80mm*45mm
Weight
200g
