TOORX MSX-70 - Assembly Step 4: Upper Frame Attachment

Assembly instructions
Place the upper frame (4) onto the front vertical frame (1) and 2 pcs guide rods (5), Carefully align the
holes and secure them with 2pcs M10*20 Allen bolt (92), 2pcs Ø10 washers (100). 2pcs M10*85
Crriage bolts(85), one pc bracket(31), 2pcsØ10 washers (100) and 2pcs M10 aircraft nuts(102).
Step 4
9
