5
❏ (4) 6" [150mm] extensions (HCAM2701 for Futaba)
❏ (2) 12" [300mm] extensions (HCAM2711 for Futaba)
❏ (5) 24" [600mm] extensions (HCAM2721 for Futaba)
❏ (1) 36" [910mm] extension (HCAM2726 for Futaba)
❏ (5) Y-harnesses (HCAM2751 for Futaba)
A minimum 2,000mAh receiver battery could be
used, but you will have to closely monitor the battery’s
capacity and voltage to avoid draining the battery
too far. A battery larger than 2,000mAh would be
more suitable and provide more fl ight time between
charges. Following are two suitable battery packs:
❏ HydriMax
™
Ultra 4.8V 4,200 mAh sub C NiMH
receiver battery w/Futaba connector (HCAM6335)
❏ HydriMax Ultra 4.8V 2,000 mAh AA NiMH receiver
battery w/Futaba connector (HCAM6321)
ADDITIONAL ITEMS REQUIRED
HARDWARE AND ACCESSORIES
In addition to the items listed in the “Decisions You
Must Make” section, following is the list of hardware
and accessories required to fi nish the B-25. Order
numbers are provided in parentheses.
❏ 1/4" R/C Foam Rubber (HCAQ1000)
❏ 3' [900mm] Standard Silicone Fuel
Tubing (GPMQ4131)
❏ Ernst #124 Charge Receptacle
❏ Stick-on Segmented Lead Weights (GPMQ4485)
❏ Propellers (and spares) suitable for your engines
ADHESIVES AND BUILDING SUPPLIES
In addition to common hobby tools and household
tools, this is the “short list” of the most important
items required to build the B-25 ARF. Great Planes
Pro
™
CA and Epoxy glue are recommended.
Foremost, a Great Planes Standard 3/32" Ball Wrench
(GPMR8002) and a Great Planes Standard .050"
Ball Wrench (GPMR8000) are virtual necessities for
assembling this model. These are long-handle Allen
wrenches that will be invaluable for mounting the
cowls and other the scale details.
❏ 1 oz. [30g] Thin Pro CA (GPMR6002)
❏ 1 oz. [30g] Medium Pro CA+ (GPMR6008)
❏ CA Applicator Tips (HCAR3780)
❏ CA Activator 2 oz. [57g] Spray Bottle (GPMR6035),
or 4 oz. [113g] Aerosol (GPMR634)
❏ Pro 30-Minute Epoxy (GPMR6047)
❏ Milled Fiberglass (GPMR6165) -OR- Microballoons
(TOPR1090)
❏ Threadlocker Thread Locking Cement (GPMR6060)
❏ #1 Hobby Knife (HCAR0105)
❏ #11 Blades (5-pack, HCAR0211)
❏ #11 Blades (100-pack, HCAR0311)
❏ Drill Bits: 1/16" [1.6mm], 5/64" [2mm], 3/32" [2.4mm],
7/64" [2.8mm], 1/8" [3.2mm], 5/32" [4mm], #29 Drill
and 4-40 Tap (or Great Planes 4-40 Tap and Drill
Set (GPMR8101)
❏ Tap handle (GPMR8120)
❏ Soldering Iron or Hobby Heat
™
Micro Torch II
(HCAR0755)
❏ Silver Solder w/Flux (GPMR8070)
❏ Denatured Alcohol for Epoxy Cleanup
❏ Plastic-Compatible Oil for Hinge Pins
❏ Rotary Tool and Cutting Bits (See Page 20)
❏ Rotary Tool Reinforced Cut-Off Wheel (GPMR8200)
❏ Fine-point felt-tip pen (Top Flite
®
Panel Line Pen—
TOPQ2510)
❏ Black Paint for Cockpit Interior
❏ Medium-Grit (220 – 320-Grit) Sandpaper
OPTIONAL SUPPLIES AND TOOLS
Here is a list of optional tools that are also mentioned
in the manual.
❏ Epoxy Brushes (6, GPMR8060)
❏ Mixing Sticks (50, GPMR8055)
❏ Mixing Cups (GPMR8056)
❏ CA Debonder (GPMR6039)
❏ Dead Center
™
Engine Mount Hole Locator
(GPMR8130)
❏ Curved-Tip Canopy Scissors for trimming plastic
parts (HCAR0667)
❏ Non-Elastic String for stab alignment (such as
K&S #801 Kevlar thread or fi shing Kevlar thread)
❏ 9/32" [7mm] O.D. K+S brass tube for fueling line
(See page 22)
❏ Masking tape (TOPR8018)
❏ 3M 77 Spray Adhesive (MMMR1990)
❏ AccuThrow Defl ection Gauge (GPMR2405)
❏ CG Machine
™
(GPMR2400)
❏ Laser Incidence Meter (GPMR4020)
❏ Precision Magnetic Prop Balancer (TOPQ5700)
COVERING TOOLS
A covering iron will be required for tightening the
covering on the model after it is removed from the
box. Following are the covering tools recommended:
❏ 21
ST
Century
®
Sealing Iron (COVR2700)
❏ 21
ST
Century Iron Cover (COVR2702)
❏ 21
ST
Century Trim Seal Iron (COVR2750)
The Top Flite B-25 ARF is factory covered with
Top Flite MonoKote fi lm. Should repairs ever
be required, following is a list of colors used on
this model and order numbers for 6' [1.8m] rolls.
(At some hobby shops MonoKote can also be
purchased by the foot.)
Flat Olive Drab (TOPQ0510)
Flat Dove Gray (TOPQ0511)
Flat Black (TOPQ0508)
White (TOPQ0204)
Note: The stabilizer and wing incidences and engine
thrust angles have been factory-built into the B-25.
However, some technically-minded modelers may
wish to check these measurements anyway. To view
this information, visit the web site at www.top-fl ite.com
and click on “Technical Data.” Due to manufacturing
tolerances which will have little or no effect on the
way the model will fl y, there may be slight deviations
between your model and the published values.
