47
Setting Name Description
Ref. Page
0
REV run command(2-wire
sequence)
Only constant H035 can be set
60
1
FWD/REV run command
(3-wire sequence)
Only constant H035 can be set
60
2 External fault (NO contact input)
3 External fault (NC contact input)
Inverter stops at fault when external
fault signal is input
Digital operator displays “EF
□*”
---
4 Fault reset
Resets fault. Fault reset is disabled
during run command input
---
5
LOCAL/REMOTE selection
---
60
6
Serial communication/control
circuit terminal selection
---
61
7 Fast stop
Decelerates to stop by decal time 2
(H022) when fast stop is input
---
8
Master frequency reference input
level selection
Master frequency reference input
level (voltage input at “open” ,
current input at “closed”) can be
selected
---
9 Multi-step speed reference 1
10 Multi-step speed reference 2
---
41
11
Jog frequency selection
---
42
12
Accel/decel time selection
---
45
13
External baseblock
(NO contact input)
14
External baseblock
(NC contact input)
Coasting signal. Motor starts
coasting when the signal is input.
Digital operator displays “bb”
(blinking)
---
15
Search command from maximum
frequency
16
Search command from set
frequency
Speed search command signals
51
17 Constant setting enable/disable
Permission or prohibition of
constant setting from the digital
operator or serial communication
(setting disabled at “closed”,
enabled at “open” ) can be selected
---
18 PID integral value reset
19 PID control disable
---
72
20 Timer function ---
61
21 OH3 (inverter overheat alarm)
When this signal is input, the
digital operator displays “OH3”
(blinking). Inverter continues
operation
---
22 Analog reference sample/hold
Analog frequency reference is
sampled at “closed and held at
“open”
62
25 UP/DOWN command Only constant H039 can be set
63
26 Loop test Only constant H039 can be set
64
