Top Gin TG300 - Appendix 2 Dimensions

72
APPENDIX 2 DIMENSIONS (mm)
TG-300 TG-250 Dimensions(mm)
WEIGHT
(KG)
220V
380V
440V
220V
380V
440V
A B C D E F G H 220V
380V
440V
L15 L15 5.5 ---
L20 L20 5.8 ---
L30 H30 L30 H30 5.9 5.7
L50 H50 L50 H50 6.6 6.2
L75 H75 L75 H75
300 289 150 126 5 12 5 195
7 6.8
L100 H100 L100 H100 320 308 200 185 5.5 7.5 5.5 230 10 10
L150 H150 L150 H150 16 16
L200 H200 L200 H200
390 373 257 235 7 11 7 250
17 17
L250 H250 L250 H250 23 22
L300 H300 L300 H300 25 24
--- H400 --- H400 --- 25
--- H500 --- H500
476 467 301 276.5 8 12.5 8 277
--- 27
L400 H600 L400 H600 57 59
L500 H750 L500 H750 60 70
L600 H1000 L600 H1000 70 72
L750 H1250 L750 H1250
685 665 420 320 8 40 8 341
75 90
H1500 H1500 --- 127
H2000 H2000 --- 142
L1000 H2500 L1000 H2500 130 145
L1500 H3000 H3000
900 875 580 459 12 60 12 340
150 160
H4000 H4000 1100 1065 760 540 12 112 12 355 --- 180
