82
U-08
Inverter status can be monitored
LED Name Description
No. Contents
U-09 Max. 4 faults can be monitored.
U-10 Lower 4 digits of PRGM No. can be monitored.
U-11
U-12
Elapsed time can be monitored as follows.
¯¯¯¯¯¯ Elapsed time (in units of hour)
U-10 (lower 4 digits)
U-11 (upper 2 digits)
Max. 279,620 hours
Montr Monitor
U-13 PID feedback can be monitored in units of 0.1 Hz.
Accel
Acceleration
time 1
Acceleration time 1 (H019) can be set/read in units of 0.1 sec (1 sec
for 1000 sec and above)
Decel
Deceleration
time 1
Deceleration time 1 (H020) can be set/read in units of 0.1 sec (1 sec
for 1000 sec and above).
Vmtr
Montor rated
voltage
Motor rated voltage (H011) can be set during stop.
V/F
V/f pattern
selection
V/f pattern selection gain (H010) can be set during stop.
Fgain
Frequency
reference gain
Frequency reference gain (H046) can be set during stop.
Fbias
Frequency
reference
bias
Frequency reference bias (H047) can be set during stop.
FLA
Motor rated
current
Motor rated current (H032) can be set during stop.
PID PID selection PID selection (H084) can be set during stop.
kWsa
v
Energy saving
selection
Energy saving selection (H095) can be set during stop.
PRG
M
PRGM mode Constants can be set/read.
11 11 11 11
1：During run
1
：Reverse run command
1：Inverter ready
1
：Fault
1
：Constant write error
from MODBUS
Always “0”
1
：MA-MC output OFF
1
：M1-M2 out
p
ut OFF
