Top TP Series - Installation; Harness Application Guide

10
Bill Acceptors
5. Installation
5-1. Harness Application
Interface Voltage Usage Harness Page
PULSE
12V DC
Power & Data Communication WEL-R7U02 8
Extension Cable CU-R961-1 9
RS232
Power & Data Communication WEL-R7U02 8
Extension Cable CU-R961-1 9
Data
Communication
WEL-R7U06 10
NOTE : Software download
Please refer to the G-BOX instruction manual for the download
manual. You can obtain it from your local agent or contact us at the
service@topvme.com.tw.
13.88
0.55
50.56
1.99
86.41
3.40
133.10
5.24
