Top TP Series - Specifications; General Specifications; Electrical Specifications; Mechanical Specifications

2
Bill Acceptors
2. Specifications
2-1. General
Acceptance Rate 96% or gr eater
Interface Pulse/RS232、Pulse/ccTalk、Pulse/ID003
Installation Indoor
Bill Inser tion Four way acceptable
2-2. Electrical
Power Source 12V DC ±5%
Power Consumption
12V DC
Standby : 350mA / 4.2W
Motor Lock : 2A / 24W
Operation
Environment
Operation Temperature : 0° C~60° C
Storage Temperature : -10° C~80° C
Humidity : 20%~70%RH
(no condensation)
2-3. Mechanica
Weight
TP1/2-P5 Approx. 1.55Kg
TP1-P8 Approx. 1.56Kg
TP1/2/3/4 Approx. 0.70kg
Outline Dimension Please refer to Chapter 4 - Dimension
Bill Box Capacity
Approx. 500 bills (P5 Series)
Approx. 800 bills (P8 Series)
Bill Accepted Width
TP1 / TP1-K : 62 ~70mm
TP2 : 66 ~77mm
TP3 : 68~83mm
3. Packing List
Main TP Bill Accept ors
Accessories
User Guide
Dip Switch Setting Guide
Harness : please refer to 5-1
Bezel Sticker
Metal Frame (Purchase)
Screw Set (Purchase)
Vandal-proof plate (Purchase)
