arms are angled inward with a connector plate for the
cross bar on the inside face of the arm. When the rudders
are in place ensure they are seated correctly so the
retaining clip springs out.
1
attaching the rudders
The connector cross bar and tiller extension are connected
together using the UJ, the cover plates need to be clipped in
place to ensure the joint cannot come apart.
When on the water the rudder blades are pushed down and
secured in place by putting the bungee loops over the
stainless steel arm.
2
rigging the spinnaker kit
system, with a shoot system for launch and retrieval of
the sail.
on the pole, the rope edge of the opening is fed around the
slot on the back of the hoop.
pole to hold it in place.
