7
lacing the trampoline
Tie loop on end of trampoline lacing line using a
bowline knot.
Then slide the loop on the lacing line over the last (far right)
nylon wheel on the rear of the rear beam (1). You can then
begin to lace the trampoline onto the rear beam.
Feed the line under rear beam, up through far right hole in
trampoline (2).
1
2
3
Then, over and around the glass rod (3), then under the
beam and back to the nylon wheel (4).
Over the top of the 1st nylon wheel (5), on to next wheel, over
the top of 2nd wheel (6), then forward under the beam (7),
and up through the eye in the rear of the trampoline around
the 10mm rod (8), then back under beam (9)...
4
