P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport
FC-6400 ULTRA-RUGGED TABLET
Main PCBA Disassembly
1. Remove Kapton tape from can.
2. Disconnect touch screen flex tail from
connector.
3. Remove five screws from main PCBA with
PH#1.
NOTE: if an ER Bluetooth module has been
removed, three of these screws will have been
removed in the process.
4. Remove ground pad from main PCBA.
