2031005555 Revision B, 04/14 6
3.3 Installing Instruments
The instruments that connect to the IS-5000 must be mounted and configured properly
before operation. The IS-5000 was designed for use with Topcon instruments.
Adjustments and/or modifications may be required for other brands of instruments or
tools.
3.3.1 Refractor
Mount the refractor onto the end of the refractor arm by removing the set screw in the
end of the shaft, sliding on the refractor, tightening the locking c lamp, and reinstalling
the set screw through the refractor clamp into the shaft. This keeps the refractor from
sliding off of the arm. If a computerized vision tester is used, repeat the same process
except feed the cable through the wire channel in the top of the arm extrusion then into
the top hole in the IS-5000 pole. Connect to the vision tester power supply.
3.3.2 Slit Lamp
Mount the Slit Lamp onto the end of the S-arm by placing the pivot pin (on the bottom
of the tabletop) into the S-arm bushing. Lock the Slit Lamp on the arm by tightening
the knob. Plug the cord into the transformer box. Refer to section 5 to counterbalance
the arm.
3.3.3 Rechargeable Instrument Handles
The instrument console is supplied with three recharging wells for use with
rechargeable instrument handles. Simply inserting them into the well charges the
instruments. Green indicator lights are provided at each well to indicate that the
instrument is in a charging condition. If the light is not lit, then the instrument is not
charging. The wells are wired at the factory at 3.5 volts DC.
3.3.4 Chart Projector (optional)
The chart projector may be mounted on the wall or on the IS-5000. If it is mounted on
the IS-5000, the chart projector arm supports any automatic chart projector. The arm
has a 0.75-inch diameter socket for mounting a projector. The maximum extension of
the arm with load, is 7 inches, and has a capacity of 22 lbs. (10 kg).
WARNING: All instruments that are attached to the IS-5000 shall be UL 60601
and CSA C22.2 compatible.
!
