Operation
LS-B2 Operator’s Manual
8
Operation
Your LS-B2 can be used alone or with a remote display.
LS-B2 Only
Using the LS-B2 only, manually control grade by raising or
lowering your cutting edge according to the LS-B2’s LED display
signals.
Basic automatic control is available using only the LS-B2, although
we recommend automatic control capability with the LS-B2/RD-2
combination.
LS-B2 and RD-2
The LS-B2 provides either automatic or manual control when used
with the RD-2 remote display. The RD-2 improves LS-B2 ease-of-
operation.
Mount the RD-2 in the machine’s cab so that the grade display
signals are within easy view. Grade signals become much easier to
see when used with the RD-2 remote display.
When the RD-2 is connected to your machine’s valves, a switch on
the front panel allows operators to select either manual or automatic
control, depending on the application. Also, the RD-2 features
switches to manually raise or lower the machine cutting edge.
These switches override automatic control.
IR-2
The LS-B2/RD-2/IR-2 combination provides an infrared
communication option for convenient wireless operation in manual
control applications. The IR-2 is an infrared receiver that connects
to the RD-2 and enables the LS-B2 grade display signals to be
transferred to the RD-2 cab-mounted display without a cable.
