Wiring the System
To supply power from your machine’s battery, wire as shown.
Otherwise, connect the LS-B2 battery pack BT-39Q.
JC
-
4 Cable
(#9060-5117)
RD
-
2
LS
-
B2
PC
-
18 Cable
(#9060-5033)
MACHINE
BATTERY
GROUND TO
MACHINE
FRAME
PC
-
18 Cable
(#9060-5033)
MACHINE
BATTERY
GROUND TO
MACHINE
FRAME
LS
-
B2
