Page11
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.

Figure13:45DegreeAdapterInstallation(IfNeeded)


5.5. MainLiftSensorInstallation
Ensure the main lift bracket matches one of the images below and that it is mounted in the appropriate
location.Thesensormustbereplaced.
1. MounttheMAXsensortothemainliftbracket.TorquetheM8nutto108in‐lb(12Nm).Runthesensor
cablethroughtheholeandbehindthebracket.Ensurethatthecableisorientedtowardthecab.

Figure14:MainLiftBracketMounting


Avoidmountingthemainliftsensoroverornearawheel‐track.Measurementsfromthewheel‐trackdonot
provideanaccuratecropheightandwillcausemeasurementandcontrolerror.
Ensurethebracketdoesnotcollidewithanyotherpartofthesprayerthroughoutthefullrangeofmainlift
motion.


