4  RemovalofOldSystem

Testtheexistingsprayerfunctionalitybeforeremovingtheoldsystem.
Donotremovethevalve blockoranyhydrauliccomponents,includinganyactive roll/activewingrollparts;
unlessdirectedtodosointhesprayerspecificinstallationguide.
4.1. UC5PartRemoval
Removethefollowingparts:
 Rollsensorsandbrackets.
 Controlmodule(locatedinthecab).
 Inputmodule(locatedontheboom).
 Valvemodule(locatedonthevalveblock).
Replacethefollowingparts:
 Height sensors and brackets (See section 5 for more information before replacing height sensor
brackets).
 Allcablesandwiringincludingthecablesconnectedtothevalveblock.

Figure3:UC5ComponentOverview
