37
MAINTENANCE
* Turn the power switch ON and check to see that the new bulb is illuminated.
(2) Replacing the fixation target bulb
* Turn the power switch OFF.
* Loosen the locking screw and remove the fixation target. (Do not over-loosen the locking
screw, or it may drop.)
* Hold the top of the bulb and pull it out; then insert the new bulb.
* Insert the fixation target, then tighten the locking screw.
* Turn the power switch ON and check to see that the fixation bulb is properly illuminated.
Guide
Locking screw
Fixation target bulb
To Next Page
