OPTIONAL ACCESSORIES

HRUBY LENS

See "(11) Mounting the Hruby Lens and Hruby Lens Guide Plate (Option)" on P.17 for mount-

ing, and "FUNDUS OBSERVATION WITH THE HRUBY LENS (OPTION)" on P.24 for using.

APPLANATION TONOMETER

Depending on personal preference, either the Haag-Streit AG Model R-900 or Model T-900

could be used for measuring intraocular pressure.

AUTOMATIC INSTRUMENT TABLE AIT-15

Specifications

• Dimensions ......................510(W)×450(D)mm

• Table height......................600~820mm

• Table size .........................490×500mm

• Weight..............................approx. 23kg

• Power consumption .........270VA

• Source voltage .................120V AC, 50/60Hz (USA and Canada)

100-120V, 220-240V AC, 50/60Hz (except for USA and Canada)

Model R900 Model T900
