Topdon BT100W - Battery Test Procedure

1. Battery Test
Note:
1) Turn off the engine and all accessories.
2) Turn on the vehicle headlamps for 10 seconds until the battery voltage drops
back to normal value if the battery is just fully charged.
3) The test only applies to 12V lead-acid batteries.
Test Steps:
1) Select "1. Battery Test".
2) Select battery type (specied on the battery label) by pressing or , and
then press "Enter".
Figure 4.1.1
Figure 4.1.2
Main Menu
Battery Type
1.Battery Test
2.Cranking Test
3.Charging Test
4.Review Data
5.Language
6.About
1.Regular Flooded
2.AGM Flat Plate
3.AGM Spiral
4.GEL
5.EFB
EN I 12
