EN I 7
SECTION 2 PRODUCT OVERVIEW
Buttons
LED indicators
Indicators
Operations
Communicates the Battery's Status
Page up; Increase the battery rated value
Figure 2.1
Good (> 80% Capacity)
Recharge (50~80% Capacity)
Replace (< 50% Capacity)
Green
Yellow
Red
Page down; Decrease the battery rated value
Cancel; Return to the previous page
Main Menu
Connects to the battery's positive terminalRed smart clamp
Connects to the battery's negative terminalBlack smart clamp
TENTER EXI
To Next Page
