Topdon BT100W - Section 4 Standalone Test Mode

Figure 4.1
Figure 4.2 Figure 4.3
Battery Test
Main Menu Main Menu
12.5V
For any of the tests (either via the device or APP), clamps must be connected
securely to the corresponding terminal, that is, black to the negative terminal (-) and
red to the positive terminal (+) (See Figure 3.4.1). After the connection is made, the
BT100W will automatically start and display the interface as shown below (See Figure
4.1):
Select your preferred language from the available 8 languages.
EN I 11
SECTION 4 STANDALONE TEST MODE
1.ENGLISH
2.French
3.German
4.Spanish
5.Italian
6.Russian
1.Battery Test
2.Cranking Test
3.Charging Test
4.Review Data
5.Language
6.About
