2.6 Station Settings 15
Motor Control
Goto: Move the motor to the stored position of the selected
satellite.
Store: Store the current position of the motor for the selected
satellite.
The followings are available only in the Installer mode.
Recalculate: Recalculate the position of the Stab Rotor motor.
Goto Ref: Go to reference.
Limit E, Limit W: Set the limits of East and West position.
Limit Off: Remove the limitation.
Reset: Reset all the stored position of the motor relative to the
‘0’ position
2.6.4 USALS Setting
USALS is very convenient mo-
torized DiSEqC system that sup-
ports DiSEqC 1.3 command and
also can get the satellite position
automatically if you know your
geographical location.
To configure the USALS settings,
select the Installation > USALS
Setting menu.
Motorized DiSEqC 1.3
Set this parameter to enable if you have DiSEqC 1.3 switch.
Satellite Name
Select a satellite that will be used to identify a motor position.
