42 Information
Table A.4: Specifications of RF-Modulator
Connector 75 Ω, IEC 169-2, Female/Male
Output Service CH21 – 69 (PAL) / CH14 – 83 (NTSC)
TV standard PAL G/I/K, NTSC-M
Table A.5: Specifications of Power Supply
Input Voltage 90 to 250 VAC, 50/60 Hz
Type SMPS
Power Consumption Running: Max. 24 W, Standby: 9 W
Protection Separate internal fuse.
The input shall have lightning protection.
Table A.6: Physical Specifications
Size (W × H × D) 260 × 46 × 190 mm
Weight 1.2 Kg
