TOPP K200T User Manual

2.6
Sliding door panel
Automation
Fig.
5a
Fig.
5b
Fig.
6
Fixed door panel
Wall end
7
K200T -K280T
EN
TYPES OF SLIDING DOORS WITH TWO PANEL
To reduce the hazard of getting the fingers caught, we recommend the assembly type as shown in Fig.5a and Fig.5b,
where the wall and/or tubular frame act as a jamb and stop the door panel.
Alternatively, proceed as shown in Fig.6 overlapping the end of the wall (and/or closing upright) with the profile of the
sliding panel and moderating the closing speed and speed of approach of the door.
@ In some countries the laws forbid this type of assembly as there is a possible risk of getting the fingers caught.
Sliding door panel
Sliding door panel
Fixed door panel
Automation
Tubular jamb
Wall end
Fixed door panel
Sliding door panel
Automation
Tubular jamb
Overlap
Sliding door panel
INSTRUCTIONS FOR INSTALLATION AND USE
