5.7- 433 Mhz RADIO REMOTE CONTROLPROGRAMMING OF
MOD. TR8/F33.
THIS CHAPTER DESCRIBES THE PROGRAMMING OF THE “433 Mhz. RADIO
REMOTE CONTROL" MOD.TR8/ F33.
The green LED DL1 blinks every time the receiver within the feeding unit receives a
valid code from the radio control, even if it has not been programmed. In this way, it is
possible to have more information on the possible malfunctions of the system.
Given that the used coding is with variable code, each remote control sends a signal
that is different from all the others. Therefore, the receiver must be able to recognise
the enabled remote controls.
To each push-button corresponds an M output:
17
TF24R/44R
INSTALLATION AND USE INSTRUCTIONS
5- INSTALLATION
M..
M..
Thermostat enabled.
Thermostat disabled.
Tab.7
Function
Position Dip-switch N.8
ON
OFF
