12
7. Technical data
All technical data are valid after a warming-up period of half an hour.
7.1 Display
Item Specification
LCD
Panel Module NC
Size 31.5” (80 cm diagonal)
Active Display Area 698.4 (H) x 392.85 (V) mm
Resolution 3840 x 2160 pixel (UHD)
Pixel Pitch 0.181(H) x 0.181(V) mm
Luminance 650cd/m2 (Panel min.)
Viewing Angle (H VType.)
178°, CR>10
Color imaging Yes
Color support 10 bit
Contrast Ratio 1700:1 (panel typical)
Response time 9.5ms(typical), gray to gray.
Back Light LED
Preset Timings Refer to “Video specification”
PIP DVI input,1920x1920 pixel
Environment
Condition
Temperature 5-40 degree C
Humidity 30-80% (without condensation)
Power
Supply
Input Voltage DC16.0-27.6V, <8.0A
Power
Consum-
ption
Normal
operation
<130W
Power saving N/A
VESA compatible arm mounting
interface
100mm x 100mm and 100mm x 200mm
Structure Dimension
750mm*444mm*60mm
7.2 Screen Performance
