9
known whether the graphics card standard can be output by the display, refer
to Section 5.1 "Connection of the flat panel display".
In order to start the unit properly, the following steps should be carried out in
the given sequence.
4.1 Connecting the power and signal cables
Warning
The display can be tilted backwards and forwards. Please pay attention not to
hurt yourself, when moving the display. Fingers or small objects may get stuck
at the bottom of the display.
Caution
Use a power cable with PE conductor corresponding to the safety
requirements of the respective country of use. Note for North America:
Molded power supply plugs must comply with the requirements for hospitals
with respect to CSA Std. C22.2 No. 21 and UL 498.The power supply and
signal connections are located on the rear of the color flat panel display.
Note
Note that the cables are already positioned when you receive the display
(power cable and DVI-D cable). The following steps are only necessary if you
need to connect/ disconnect the cables of the scope of supply.
4.1.1 Cable (attaching)
Connect the cables to the display.
Power cable: The Power cable connection is used for display power supply.
