1

OPERATION AND MAINTENANCE

MODELS TX-1, TX-2, TX-4, TX-8, TX-16, TX-32, TX-45

MANUAL

TX Series

Low Prole Hydraulic Torque Wrenches

TX Series

Phone: +1 610-250-5800

Fax: +1 610-250-2700

Toll Free: 1-888-TORCUP-1

Email: sales@torcup.com

Website: www.torcup.com

1025 Conroy Place, Easton PA 18040 U.S.A.

Other manuals for TorcUP TX-16

Operating And Maintenance Instructions20 pages

Questions and Answers

M
Michele CooperAug 5, 2025
Why is my TorcUP TX-16 pump not building up pressure?
- A
  Angela RussellAug 5, 2025
  If your TorcUP Power Tool pump isn't building up pressure, several factors could be at play. Begin by checking the relief valve for any defects, and consider adjusting or replacing it if necessary. Ensure that your air supply and hose size meet the recommendations outlined in the pump manual. For electric pumps, verify that the amperage, voltage, and extension cord size are compliant with the pump manual's requirements. Replace the gauge if it is defective. Also, check the oil level and replenish the pump reservoir if it's low. Lastly, inspect the pump filter for clogs; clean or replace it as needed.
S
schmittchristineAug 9, 2025
What to do if my TorcUP TX-16 tightens immediately when turned on?
- R
  Raymond WebbAug 9, 2025
  If your TorcUP Power Tool tightens immediately upon activation, the hose connections are likely reversed. To correct this, depress the advance button to release the tool, then switch off the pump while it's in the advance position. Finally, reverse the hose connections.
M
Michael StoneAug 13, 2025
How to fix a TorcUP TX-16 Power Tool when the piston will not advance or retract?
- M
  mcculloughangelaAug 13, 2025
  If the piston of your TorcUP Power Tool isn't advancing or retracting, start by checking the coupler connections to ensure they are securely attached to both the tool and the pump. Replace any couplers that are defective. If the issue persists, the remote control switch may be faulty, requiring replacement of the switch or control pendant. Another potential cause is dirt in the direction-control valve of the pump unit, which would necessitate disassembling the pump and cleaning the valve.
C
carolsmithAug 18, 2025
What to do if the cylinder of my TorcUP TX-16 Power Tool will not build up pressure?
- A
  andrea60Aug 18, 2025
  If your TorcUP Power Tool's cylinder isn't building up pressure, it could be due to several reasons. Start by checking the piston seal and end plug seal for leaks, and replace any defective o-rings. Also, inspect the retaining screws for shearing and replace any that are broken. Finally, a defective coupler could also be the cause, so replace any that are faulty.
J
Juan JohnsonAug 21, 2025
Why won't the piston retract on my TorcUP TX-16?
- D
  Dennis EdwardsAug 22, 2025
  If the piston on your TorcUP Power Tool won't retract, first ensure that the hose connections are correct: the advance on the pump should connect to the advance on the tool, and the retract on the pump should connect to the retract on the tool. Next, verify that the retract hose is securely connected. Lastly, check for a broken retract pin or spring and replace them if necessary.
H
hcolemanAug 26, 2025
How to troubleshoot a TorcUP TX-16 when the ratchet will not turn?
- D
  Donna AndrewsAug 26, 2025
  If the ratchet on your TorcUP Power Tool isn't turning, it could be due to a buildup of grease or dirt in the teeth of the ratchet link and drive segment. Disassemble the ratchet and clean out any grease or dirt. Alternatively, the teeth on the ratchet or drive segment may be worn or broken, requiring replacement of the damaged parts.
J
Jennifer WhiteAug 30, 2025
What causes erratic pressure readings in a TorcUP Power Tool?
- P
  Paul BartonAug 30, 2025
  If you observe erratic pressure readings on your TorcUP Power Tool, the gauge is likely defective and needs to be replaced.

Summary

TX Series Operation and Maintenance Manual

TX Series Hydraulic Torque Wrenches Overview

Overview of the TX Series Low Profile Hydraulic Torque Wrenches and their models.

Essential Safety Warnings and Usage

Critical safety information and initial operational guidelines for the torque wrench.

Tool Setup and Operation

Connecting and Setting Torque

Procedure for connecting the tool and setting the desired torque.

Operating the Hydraulic Torque Wrench

Instructions on how to properly operate the hydraulic torque wrench during use.

Technical Specifications and Parts

Technical and Dimensional Data

Detailed specifications and dimensions for the TX Series wrenches.

Exploded Views and Part Numbers

Diagrams and part lists for cylinder and link assemblies of various models.

Maintenance and Troubleshooting

Maintenance and Disassembly Procedures

Steps for disassembling cylinder and ratchet link assemblies.

Assembly Procedures

Instructions for reassembling the hydraulic torque wrench components.

Troubleshooting Common Issues

Guide for diagnosing and resolving common problems with the torque wrench.
