39
MAINTENANCE SECTION
In the following step, an excessive amount of grease will prevent
proper tooth engagement between the ratchet and the drive
segment, causing the tool to malfunction.
7. Wipe a thin lm of Marine Moly Grease onto the inner face of the large opening in the drive plate.
8. Position the ratchet (6) in the central opening of the drive plate.
9. Insert the drive segment (7) into the opening adjacent to the ratchet. Make certain the teeth of
the ratchet correctly engage the teeth of the drive segment. Reverse the ratchet if they do not
properly engage.
10. Slide the drive segment sideways to expose the spring hole. Install the segment spring (14) into the
hole. While compressing the spring, slide the drive segment inward until the drive plate captures
the segment spring.
11. Apply a light coat of Marine Moly Grease to both sides of the drive plate and drive segment as well
as the inner races of both side plate sleeves (12).
12. While keeping the assembly together, insert the hub of the ratchet into the side plate sleeve of the
assembled side plate.
13. Place the left side plate sleeve on the hub of the ratchet and align the screw holes for the spacers.
14. After applying a non-permanent thread-locking compound to the threads and using hex wrenches,
install the two remaining lower spacer screws.
ASSEMBLY OF THE TOOL
1. With the cylinder assembly in one hand and the ratchet link in the other, hook the notch on the
shaft of the piston rod (2A) onto the drive pin (4) and bring the two assemblies together.
2. Insert the link pin (9) into the hole in the side plate (1 or 2) until the link pin snaps into the link
retaining spring (21).
NOTICE
