32
TX-32/45 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-32-L01- #* 1
2 Side Plate - Right TX-32-L02- #* 1
3 Drive Plate TX-32-L03- #* 1
4 Drive Pin TX-32-L05 1
5 Drive Pin Spring TX-32-L07 1
6 Ratchet TX-32-L09- #* 1
7 Drive Segment TX-32-L11- #* 1
8 Upper Spacer TX-32-L13 1
9 Middle Spacer TX-32-L14- #* 1
10 Lower Spacer TX-32-L15- #* 1
11 Spacer Pin TX-32-L17 2
12 Sideplate Sleeve TX-32-L19- #* 2
13 Shroud TX-32-L21 1
14 Segment Spring TX-32-L25 1
15 Upper Spacer Screw TX-32-L27 4
16 Lower Spacer Screw TX-32-L29 4
17 Shroud Screw TX-32-L31 2
18 Dr. Pin Spring Roll Pin TX-32-L33 1
19 Spacer Roll Pin TX-32-L35 1
*part number is dependent upon ratchet link size
