TXU Series Uni-Swivel Wrench Technical & Dimensional Data
Model Number TXU-32
Min. Torque (ft/lbs) 3220
Max. Torque (ft/lbs) 35650
Min. Torque (nm) 4365
Max. Torque (nm) 48327
Output Accuracy +/-3%
Repeatability 100%
Duty Cycle 100%
Cylinder Weight (lbs/kg) 27.1/12.3
Link Weight
(lbs) 29.0-35.5
(kg) 13.0-17.9
Length 1 (in/mm) 15.80/401.3
Length 2 (in/mm) 9.31/236.5
Width 1 (in/mm) 3.24/82.3
Width 2 (in/mm) 2.26/57.4
Radius (in/mm) 0.93/23.6
Height 1 (in/mm) 9.50/241.3
Height 2 (in/mm) 1.30/33.0
Hex Range from 3 1/8”/80mm
Hex Range to 7 7/8”/200mm
