OWNER’S MANUAL

3 Ton Low Prole Service Jack

Item: T83508

Questions, problems, missing parts? Before returning to your retailer, call our customer service department at

1-888-44-TORIN (1-888-448-6746), 8 a.m.- 5 p.m., PST, Monday-Friday.

Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure

to follow the safety rules and other basic safety precautions may result in serious personal injury.

Version 20161111

Questions and Answers:

E
emilyleeJul 28, 2025
What to do if my Torin Jacks will not lift load?
- K
  kjohnsonJul 29, 2025
  If your Torin Jacks won't lift the load, several factors could be at play. First, ensure the release valve is fully closed by turning the handle clockwise. It's also possible the weight exceeds the jack's capacity. Another potential cause is air in the hydraulic system, which requires purging. A low oil level can also prevent lifting, so add oil as needed. Lastly, a malfunctioning power unit may be the culprit, necessitating its replacement.
M
Ms. Stephanie BowmanAug 4, 2025
What to do if my Torin BIG RED T83508 will not hold load?
- A
  Andrew GriffithAug 4, 2025
  If your Torin Jacks fails to hold a load, check these potential causes: the release valve might not be completely closed, so turn the handle clockwise to secure it. A low oil level could also be the problem, requiring you to add more oil. In some cases, a malfunctioning power unit could be responsible, and it would need to be replaced.
R
roy21Aug 9, 2025
What to do if my Torin Jacks will not lower?
- T
  Teresa AyersAug 9, 2025
  If your Torin Jacks won't lower, it could be due to exceeding the weight capacity. Also, if the oil reservoir is overfilled, drain the excessive oil and lubricate moving parts. The jack might also be binding or there could be a foreign obstruction.
S
Sarah WilsonAug 16, 2025
How to fix Torin BIG RED T83508 that will not lift to full extension?
- C
  Caitlin HillAug 16, 2025
  If your Torin Jacks isn't reaching its full extension, the issue might be due to a low oil level, in which case you should add oil as required. Alternatively, the power unit could be malfunctioning, and you may need to replace it.
