Washroom Dispenser Service and Parts Manual
Tork Bath Tissue Roll Dispenser
209303A, 209305A Revision Date: 2-17-10
2. Replace the mandrel in the
dispenser by inserting it into the top,
noting it only fits one way (2a). Place
the roll into the top of the dispenser
(2b). Close the cover and remove the
Tork key.
Reloading Instructions
1. Open the cover with the supplied Tork
key. The spindle with the used core drops
out of the bottom of the dispenser (1a).
Remove the used core and place a full,
unwrapped roll on the spindle (1b). Do not
try to pull the mandrel up through the top
of the dispenser.
2. Lift the new roll up and
around (2a) until it is now
on the top (2b). Drop the
roll into the top of the
dispenser (2c). Close the
cover and remove the Tork
key (2d).
Preventive Maintenance
The Tork Bath Tissue dispenser should be cleaned any time there is heavy paper dust build-up
inside the dispenser. If paper dust is not a problem, approximately every year is a good
frequency for cleanings. The following is the recommended procedure to cleaning:
1) Open the dispenser and remove the rolls of paper.
