Tormach 770M Installation Guide

3.1 EXPLODED VIEWS AND PARTS LISTS
3.1.2 Enclosure Parts List
ID Description Quantity
1 Enclosure Panel, 770, Lower Front (PN 37600) 1
2 Enclosure Panel, 770M, Left Front (PN 37603) 1
3 Enclosure Panel, 770M, Right Front (PN 37601) 1
4 Enclosure Panel, 770, Upper Front (PN 37605) 1
5 Enclosure Panel, 770M, Left Side (PN 37604) 1
6 Enclosure Panel, 770M, Right Side (PN 37602) 1
7 Enclosure Panel, 770, Left Top (PN 37614) 1
8 Enclosure Panel, 770, Right Top (PN 37615) 1
9 Enclosure Panel, 770, Left Rear (PN 37616) 1
10 Enclosure Panel, 770, ATC (PN 37617) 1
11 Chip Tray Rail, 770 (PN 37662) 1
12 Enclosure Panel, 770, Right Rear (PN 37619) 1
13 Enclosure Panel, 770M, Splash Shield (PN 38479) 1
14 Enclosure Panel, 770, Splice Plate (PN 38480) 1
15 Enclosure Panel, 770, Column Splice (PN 37618) 1
16 Enclosure Door, 770, Right (PN 37609) 1
17 Window, 770M, Right Door (PN 37624) 1
18 Enclosure Door, 770, Left (PN 37608) 1
19 Window, 770M, Left Door (PN 37623) 1
20 Window, 770, Side (PN 37625) 2
21 Enclosure Window Retainer, 770, Vertical (PN 37620) 8
22 Enclosure Window Retainer, 770, Horizontal (PN 37621) 8
23 LED Floodlight, 50 W (PN 37341) 2
24 Flood Light Retainer (PN 38222) 4
25 Linear Rail Mount (PN 37622) 8
26 Left Door Rail, 770 (PN 37606) 2
27 Right Door Rail, 770 (PN 37607) 2
28 Linear Bearing (PN 37610) 8
29 Door Bumper (PN 38357) 8
30 Handle, 400 mm (PN 37611) 2
31 Enclosure Ball Latch, Male (PN 38483) 1
Page 24
©Tormach® 2022
Specifications subject to change without notice.
tormach.com
TD10536: Installation Guide: 770M Enclosure (0522A)
