26
MAINTENANCE
6. Reassemble the filter.
AUTOMATIC DISASSEMBLING OF THE BRUSH
1. Put the drive selector lever in the central position.
2. Turn on the machine turning the key clockwise (1).
3. Keep the button (2) pressed for a few seconds.
4. Turn off the machine.
CLEANING THE BRUSH
Take off the brush to clean it with a water jet (to read how to do it see chapter “DISASSEMBLING
THE BRUSH”).
CLEANING THE SQUEEGEE
Keeping the squeegee clean ensures a better floor cleaning:
1. Lift the brush base, then rotate the squeegee on the side.
2. With the squeegee in such position, take off the squeegee hose coupling (1).
3. Completely unscrew the wing nuts (2) in order to release the squeegee.
4. Carefully clean the joint of the squeegee cleaning eventual dirt deposits and carefully clean
also the squeegee rubbers.
