Installing
the
Reel
Motors
(continued)
G41
1002
4.
Rotate
the
motor
counterclockwise
until
the
flanges
encircle
the
bolts,
and
then
tighten
the
bolts.
IMPORT
ANT
Ensure
that
the
reel
motor
hoses
are
not
twisted,
kinked,
or
at
risk
of
being
pinched.
5.
T
orque
the
mounting
bolts
to
37
to
45
N∙m
(27
to
33
ft-lb)
.
3464-482A
Page
3–1
1
Setup:
Installing
the
Cutting
Units
30
32
