g003995
Figure55
1.Bypassvalve
2.Closethebypassvalvebeforestartingthe
engine.However,donotexceed7-11N-m.(5-8
ft.-lb)torquetoclosethevalve.
Important:Runningtheenginewith
thebypassvalveopenwillcausethe
transmissiontooverheat.
JackingPoints
Note:Usejackstandstosupportthemachinewhen
required.
•Front—rectangularpad,undertheaxletube,
insideeachfronttire(Figure56).
g004554
Figure56
1.Frontjackingpoint
•Rear—rectangularaxletubeontherearaxle.
TieDowns
•Front—theholeintherectangularpad,underthe
axletube,insideeachfronttire(Figure57).
g004558
Figure57
1.Fronttiedown
•Rear—eachsideofthemachineontherearframe
(Figure58).
g004555
Figure58
1.Reartiedown
