ServiceIntervalChart

decal125-2927

Figure60

CAUTION

Ifyouleavethekeyintheignitionswitch,someonecouldaccidentlystarttheengineand

seriouslyinjureyouorotherbystanders.

Removethekeyfromtheignitionbeforeyoudoanymaintenance.

Lubrication

GreasingtheBearingsand

Bushings

Ifyouoperatethemachineundernormalconditions,

lubricateallgreasettingsforthebearingsand

bushingsafterevery50hoursofoperationwithNo.

2GeneralPurposeLithiumBaseGrease.Lubricate

bearingsandbushingsimmediatelyafterevery

washing,regardlessoftheintervallisted.

Thegreasettinglocationsandquantitiesareas

follows:

•Pumpdriveshaft(3)(Figure61)

g021216

Figure61

•Cuttingunitliftarmcylinders(2each)(Figure62)

g012150

Figure62
