Toro 03681 - Adjusting the Rear Shield; Mount the Counter Weights

Figure3
1.Cuttingunitkickstand
3
AdjustingtheRearShield
NoPartsRequired
Procedure
Undermostconditions,bestdispersionisattained
whentherearshieldisclosed(frontdischarge).
Whenconditionsareheavyorwet,rearshieldmay
beopened.
Toopentherearshield(Figure4),loosenthecapscrew
securingtheshieldtotheleftsideplate,rotatethe
shieldtotheopenpositionandtightenthecapscrew.
Figure4
1.Rearshield
2.Capscrew
4
MounttheCounterWeights
NoPartsRequired
Procedure
Allcuttingunitsareshippedwiththecounterweight
mountedtotheleftendofthecuttingunit.Usethe
followingdiagramtodeterminethepositionofthe
counterweightsandreelmotors.
Figure5
1.Onthe#2and#4cuttingunits,removethe2cap
screwssecuringthecounterweighttotheleftend
ofthecuttingunit.Removethecounterweight
(Figure6).
5
