ProductOverview
Specications
Tractors
ThesecuttingunitswillmountontheReelmaster5510&5610TractionUnits.
HeightofCutCuttingheightisadjustedonthefrontrollerbytwoverticalscrewsandheldbytwolocking
capscrews
HeightOfCutRangeStandardbenchheightofcutrangeis.250inch(3mm)to1.00inch(25mm).Benchheight
ofcutrangewiththeHighHeightofCutKitinstalledis1.00inch(25mm)to2.00inches
(51mm).EffectiveHOCmayvarydependingonturfconditions,typeofbedknife,rollers
andattachmentsinstalled.
ReelWeldment
Reelsare7inches(18cm.)indiameter,22inches(56cm.)inlength.Highstrengthlow
alloysteelbladesarethruhardenedandimpactresistant.
ReelBearings
Twodoublerowself-aligningballbearings,presstontoreelshaft.
PowerAttachmentDiecastaluminumcrossmemberwiththreebolt-ondie-castaluminumsideplates.
Frame
Thefrontrollerisa3inch(76mm)diameterplasticWiehleroller.Therearrollerisa3.0inch
(76mm)diametersteelfullroller.
Rollers
Replaceablesingleedged,highcarbonsteelbedknifeisfastenedtoamachinedcastiron
bedbarwith8screws.TheEdgeMaxtbedknifeisstandard.
BedknifeReplaceablesingleedged,highcarbonsteelbedknifeisfastenedtoamachinedcastiron
bedbarwith8screws.TheEdgeMaxtbedknifeisstandard.
BedknifeAdjustmentDualscrewadjustmenttothereel;detentscorrespondingto.0009inch(.023mm)bedknife
movementforeachindexedposition.
GrassShieldAdjustablerearshieldwithoptionaladjustablecut-offbartoimprovegrassdischargefrom
reelinwetconditions.
Counterweight
Acastironweightmountedoppositetothedrivemotorbalancesthecuttingunit.
MaximumReelSpeed
1650RPM.
Weight
8Blade–147lb.(67kg)
11Blade–151lb.(69kg)
