Figure4
1.Hoodlatch
2.Removethe(2)rivetssecuringthehoodlatchbracket
tothehood(Figure5).Removethehoodlatch
bracketfromthehood.
G012628
1
2
Figure5
1.Hoodlatchbracket2.Rivets
3.Whilealigningthemountingholes,positiontheCE
lockbracketandthehoodlatchbracketontothe
hood.Thelockbracketmustbeagainstthehood
(Figure5).Donotremoveboltandnutassembly
fromthelockbracketarm.
G012629
1
2
Figure6
1.CElockbracket
2.Boltandnutassembly
4.Alignthewasherswiththeholesontheinsideofthe
hood.
5.Rivetthebracketsandthewasherstothehood
(Figure6).
6.Hookthelatchontothehoodlatchbracket
(
Figure7).
G012630
1
Figure7
1.Hoodlatch
7.Screwtheboltintotheotherarmofhoodlock
brackettolockthelatchinposition(Figure8).
Tightenboltsecurelybutdonottightennut.
G012631
1
2
3
Figure8
1.Bolt
3.Armofhoodlockbracket
2.Nut
