Figure30
1.Reelspeedcontrols
FuelGauge
Thefuelgauge(Figure31)indicatestheleveloffuelin
thetank.
Figure31
1.Fuelgauge
SeatAdjustments
ForeandAftAdjustingLever
Pulloutonthelevertoslidetheseatforeoraft
(Figure32).
SeatArmRestAdjustingKnob
Rotatetheknobtoadjusttheseatarmrestangle
(Figure32).
SeatBackAdjustingLever
Movethelevertoadjusttheseatbackangle(Figure32).
Weightgauge
Indicateswhentheseatisadjustedtotheweightofthe
operator(Figure32).Heightadjustmentismadeby
positioningthesuspensionwithintherangeofthegreen
region.
Figure32
1.Weightgauge
4.Seatbackadjustinglever
2.Weightadjustinglever5.Armrestadjustingknob
3.ForeandAftadjusting
lever
WeightAdjustingLever
Adjustforoperatorweight(Figure32).Pulluponthe
levertoincreasetheairpressureandpushdownto
decreasetheairpressure.Theproperadjustmentis
attainedwhentheweightgaugeisinthegreenregion.
